PPE - Premium MicroPure XR Engine Oil Filter Kit - 2020-2026 GM 6.6L L5P Duramax - 114000750 + 114002700

Part # 114000750 & 114002700

OEM P/N REFERENCE: PF26, FL-820-S, MO-899

NOTE: The included Fuel Coolant Pump Relocation Bracket Kit is required for the install of this deep filter.

Replace your stock engine oil filter with this high-capacity high-efficiency deep filter for overall better engine protection.  The stock PF26 has a 25 to 30 micron rating that can let through some very large debris, lessening the life of your motor.  With the upgrade filter, you get over double the filter media at a 5 micron rating.

FEATURES

• MicroPure XR® filtration with a 5-micron nominal rating
• 522 Square inches of ultra-fine synthetic microfiber media, a 100% increase over the stock filter
• Integrated high-temperature rated neodymium magnet captures ferrous particles, providing extra engine protection
• Built-in bypass valve with precision coil spring and steel-NBR poppet
• High-strength steel base plate with increased thread engagement and large oil passages
• Durable metal center tube provides excellent media support and pressure resistance
• TorqSTOP™ Technology prevents over-tightening and reinforces the gasket against high oil pressures
• Silicone anti-drain-back valve delivers superior protection during engine start-ups
• Heavy-duty coil spring ensures a secure seal and prevents oil blow-by, maximizing filtration performance
• Pleat-locking spiral bead keeps media pleats evenly spaced for consistent filtration performance
